Coilover Kit BMW BMW 5 Series E12
Coilover Kit MTS Technik for BMW 5 Series / E12, lowering the front axle between 25 - 100 mm, and rear between 45 - 140 mm. Dedicated for the years of: 03/72 - 08/81, for the engine version: 518 / 520 / 520 i / 520/6 / 525 / 528 / 528 i / M535 i.
2 year warranty with no mileage limit to confirm high quality.
Suspension components characterized by increased corrosion resistance and made of the highest quality materials.
The use of twin-tube technology guarantees stable shock absorber performance.
Pressurized gas presses the hydraulic fluid, eliminating the "foaming" effect of the oil (an undesirable and typical for oil shock absorbers phenomenon), which means higher efficiency for continuous, intensive work.
Specially selected type of thread and a wide range of suspension adjustment allows optimal setting of the car height.
Innovative hexaCOIL spring perch, significantly increasing the comfort of suspension height adjustment.
Double zinc plated steel shock absorbers as well as anodized aluminum adjusters and caps to ensure increased corrosion resistance.
Coilover springs made by Eibach, the world leader in the sport springs industry.
CAR:
Make |
BMW
|
Model |
5 Series / E12
|
Type |
E12
|
Engine |
518 / 520 / 520 i / 520/6 / 525 / 528 / 528 i / M535 i
|
Year |
03/72 - 08/81
|
TECH SPECS:
Series: | street |
Max. Axle Load FA: |
940 kg
|
Max. Axle Load RA: |
1010 kg
|
Lowering FA: |
25 - 100 mm
|
Lowering RA: |
45 - 140 mm
|
Coilover Main Spring (Front): |
Spring rate (60 N/mm)
|
Coilover Helper Spring (Front): |
Spring rate (20 N/mm)
|
Coilover Main Spring (Rear): |
Spring rate (50 N/mm)
|
Coilover Helper Spring (Rear): |
Spring rate (20 N/mm)
|
TUV Certificate: |
no
|
Download instruction: | Download instruction |
Download installation manual: | Download installation manual |
PRODUCT NOTES
2 - Front and rear axle height adjustable (threaded shock absorber housing).
21 - If the vehicle is equipped with a stock sport suspension, the lowering mentioned in this catalogue will be relatively lower.
24 - During the installation of suspension set the clearance between tire/rim and suspension strut shall be checked. The minimum allowed gap is 5mm (0,2 inch). Otherwise use certificated wheel spacers.
26 - Independent height adjustment at the lower brackets on the front dampers.
28 - Set includes 2x upper "camber plates" on the front axle.
29 - The installation requires the use of OE front struts - they should be cut and welded as described in the attached manual.
65 - Suspension compatible only with a rear top mount with an internal diameter of 78mm - OEM number: 33521117657 or 33521126987. It is possible to mount the suspension to cars equipped with other top mounts, but original parts marked with one of the above numbers will be required.
66 - In the case of cars equipped with Nivo, it will be required to replace the rear top mounts with OEM: 33521117657 or 33521126987.
MATCHES TO
Make | Model | Engine | Year |
BMW |
5 Series / E12
|
518 / 520 / 520 i / 520/6 / 525 / 528 / 528 i / M535 i
|
03/72 - 08/81
|
THE IMAGE/S OF THIS PRODUCT MAY BE EXACT OR GENERIC AND ARE INTENDED FOR ONLINE VISUAL REFERENCE ONLY AND MAY NOT REFLECT THE ACTUAL CONTENTS, ACCESSORIES OR CONFIGURATION OF THE PRODUCT.
GENERALLY ALL KITS WILL INCLUDE NECESSARY ITEMS TO INSTALL OR RE-USE ORIGINAL PARTS INCLUDING BOLTS, SCREWS, ETC. FOR INSTALLATION. IF YOU ARE UNSURE PLEASE CONTACT US PRIOR TO PURCHASING.
